Technical specification - Basic Model:
1.Construction - Oudoor use:
- Modern designed metal body rugged construction of steel sheets 1.5 mm,
- Access to service from front site,
- Coating painting in RAL 9006 White Aluminium,
- Anti theft system lock with 4 point locking with security lock, which prevents unauthorized access to components
inside the device and provides resistance to vandalism,
- Each device are provided with various keys. On user request we supplies the master key that opens all the
devices,
- Sealing system for protection for external use - Outdoor,
- Removable front panel. Upgrade device is enabled by replacing front panel and mounting new one with
accessories,
- Clasp ON / OFF with a round connector,
- Kopp power splitter with 5 outlets and surge protection 16A 250V ~, max. 3.600 W, IP 20, "
- Wall brackets,
PC:
- Motherboard, DDR3, sound, SATA, GLAN, PCI-E, D-SUB, mATX, s.
- Processor INTEL 1155, 2.5GHz, 2.5MB cache, GPU, DualCore
- Memory, 2 GB, DDR3
- HDD SSD
- Power 420W, ATX2, 80mm vent,
LCD monitor 17", with maximum resolution 1280 x 1024 dpi.
Anti-vandal Surface Acoustic Wave (SAW) touch screen in 6mm-thickness heat strengthened glass, meets UL1950
standard with the ABS plastic frame covered around the touch sensor. It features dustproof, waterproof and
break resistance.
Dimensions: H 918 x W 500 x D263 mm / Weight: 30 kg
